| Product Specifications |
| Infrared temperature range |
-40°C to 800°C (-40°F to 1472°F) |
| Infrared accuracy |
< 0°C (32°F): ±(1.0°C (±2.0°F) + 0.1°/1°C or°F); |
| > 0°C (32°F): ±1% or ±1.0°C (±2.0°F), whichever is greater |
| Display resolution |
0.1°C / 0.1°F |
| Infrared spectral response |
8 µm to 14 µm |
| Infrared response time |
< 500 msec |
| Thermocouple Type-K input temperature range |
-270°C to 1372°C (-454°F to 2501°F) |
| Thermocouple Type-K input accuracy |
-270°C to -40°C |
±(1°C + 0.2°/1°C) (-454°F to -40°F: ±(2°F + 0.2°/1°F)) |
| -40°C to 1372°C |
±1% or 1°C (-40°F to 2501°F: ±1% or 2°F), whichever is greater |
| D:S (distance to measurement spot size) |
50:1 |
| Laser sighting |
Single-point laser < 1 mw output Class 2 (II) operation, 630 nm to 670 nm |
| Minimum spot size |
19 mm (0.75 in) |
| Emissivity adjustment |
By built-in table of common materials or digitally adjustable from 0.10 to 1.00 by 0.01 |
| Data storage with date/time stamp |
99 points |
| PC interface and cable |
USB 2.0 with FlukeView® Forms software |
| Hi/Low alarms |
Audible and two-color visual |
| Min/Max/Avg/Dif |
Yes |
| Display |
Dot matrix 98 x 96 pixels with function menus |
| Backlight |
Two levels, normal and extra bright for darker environments |
| Trigger lock |
Yes |
| Switchable Celsius and Fahrenheit |
Yes |
| Power |
2 AA/LR6 Batteries and USB when used with a PC |
| Battery life |
If used continuously |
Laser and backlight on,12 hours; laser and backlight off, 100 hours |
| Operating temperature |
0°C to 50°C (32°F to 122°F) |
| Storage temperature |
-20°C to 60°C (-40°F to 140°F) |
| Bead thermocouple Type-K range |
-40°C to 260°C (-40°F to 500°F) |
| Bead thermocouple Type-K accuracy |
±1.1°C (2.0°F) from 0°C to 260°C (32°F to 500°F), typically within 1.1°C (2.0°F) from -40°C to 0°C (-40°F to 32°F) |
